Building Integrated Photovoltaic Mounting System , BIPV Panel Mounting System

Minimum Order Quantity : 5 set Price : USD1500-2000/set
Packaging Details : 1.Carton box,wooden pallet,belt bundle packing and other kinds of package ensure the products safty and waterproof. 2.Customized packing Delivery Time : 15-25 work days
Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram Supply Ability : 30MW/month
Place of Origin: CHINA Brand Name: TIANFON
Certification: SGS,ISO 9001,ISO 14001,OHSAS 18000 Model Number: Greenhouse Solar System

Detail Information

Name: Greenhouse Solar Structure And Design Solution Color: Natural Or Customized
Specification: As Required Application: Industrial,Commercial
Tilt Angle: 10/15/20/30/ Customized Material:: Q235B, Q345B, Al6005
High Light:

farm solar power systems

,

solar pv mounting systems

Product Description

Building Integrated Photovoltaics BIPV Greenhouse Solar Structure and Design Solution



The solar panels could be tilted at certain angle, leaving some gap from each side of the solar panels to meet the sunshine demands of crops. All components are made of according to your requirement.
The technology is transferable from a domestic to an industrial scale without adverse affect on plant growth or temperatures within.
The modules are easy to be assembled and unassembled, and are designed to facilitate the adjustment of light transmittance in order to meet the growth need of crops.



Data:



 Material  Galvanized stainless steel
 Module array  Two vertical or customized
 Base  Static pressure tube pile
 Column  Hot rolled plain steel
 Beam  C steel
 Purline  C steel
 Span  As required
 Tilt angle  10-60°
 Panel type  Frame/ Frameless
 Wind speed  60m/s
 Snow load  1.4kn/square meter
 OEM mounting parts  Accepted
 Remark  Bracket technical data should be changed if module spec changed



Benefit:



1. Easy installation

The pre-assembled design of the highest level in factory simplifies construction site work to the largest degree and therefore installation is simple and quick. It can effectively improve construction efficiency, shorten construction period and reduce construction costs.



2. Safety

The racking systems can stand up to the extreme weather condition. The main support components have also been tested to guarantee its structure and load-carrying capacity.



3. Excellent Compatibility

The Tianfon mounting system compatible with most of the major framed and frameless PV modules on the market.



4. Widely application

The mounting system suitable for various kinds of project, including residential project, commercial project, utility project and so on.



5. Shorten construction period
Reduced installatin times due to high pre-fabrication leve; MInimized assembly time and effort (up to 40%).



6. Customized Design
According to the project needs, adjust the light transmission rate, and make full use of the land.



Building Integrated Photovoltaic Mounting System , BIPV Panel Mounting System 0





Building Integrated Photovoltaic Mounting System , BIPV Panel Mounting System 1
