315W 320W 325W ERA Mono Advanced Glass 60 Cell Solar Panel Solar System Components

Payment Terms : L/C, T/T Supply Ability : 1000 Watt/Watts
Place of Origin: CHINA Brand Name: TIANFON
Certification: SGS,ISO 9001,ISO 14001,OHSAS 18000 Model Number: Solar Panels

Detail Information

Size: 1665x1002x35mm Weight: 19 Kg
Backsheet (color): TPT In Black Company Certificate: ISO9001,ISO14001,ISO18001
Front Cover (material / Thickness): Low-iron Tempered Glass / 3.2mm Cell (quantity / Material / Dimensions): 60 / Monocrystalline Silicon / 158.75x158.75mm
Frame (material / Color): Aluminum Hollow-chamber Frame On Each Side Anodized Aluminum Alloy / Silver Cables & Plug Connectors (protection Degree): 2x900mm / 4mm 2 & MC4 Compatible
Payment Terms: L/C, T/T
High Light:

Advanced Glass 60 Cell Solar Panel


ERA 60 Cell Solar Panel


Advanced Glass Solar Panels

Product Description


ERA 315W-325W Mono 60 Cell Advanced Glass Solar Panel


We have paced the whole nation in the field of PV industry, not only on its product lines, but also upon its innovation.


We serves global customers with high-quality products and professional services. The modules can be installed on residential and commercial rooftops, ground-mounted power plants, as floating arrays, and much more.


Other than our competitive prices for pv modules and related solar energy products, we also offer the most comprehensive and accessible customer support for you.




Module type: ESPHSC 315M 320M 325M
Maximum Power(Wp) 315W 320W 325W
Open circuit Voltage(Voc) 41.95V 41.24V 41.44V
Short circuit Current(Isc) 9.8A 9.88A 9.96A
Maximum Power Voltage(Vm) 33.41V 33.68V 33.93V
Maximum Power Current(Im) 9.43A 9.51A 9.58A
Module efficiency 18.88% 19.18% 19.48%
Maximum Series Fuse 15A
Watts positive tolerance 0~+3%
Number of Diode 3
Standard Test Conditions 1000W/M²,25°C,AM1.5
Maximum System Voltage 1000V/DC
Temperature-Coefficient Isc JIA0.08558%/°C
Temperature-Coefficient Voc -0.29506%/°C
Temperature-Coefficient Pmpp -0.38001%/°C
Normal Operating Cell Temperature -40°C...+85°C
Load Capacity for the cover of the module (glass) 5400Pa(IEC61215)(snow)
Load Capacity for the front & back of the module 2400Pa(IEC61215)(wind)
Product Certificate TUV(IEC 61215,IEC 61730),CE, ROHS,PID Resisitant,INMETRO
Company Certificate ISO9001,ISO14001,ISO18001

Key Features:


► 5 Busbar Solar Cell:
5 busbar solar cell adopts new technology to improve the efficiency of
modules , offers a better aesthetic appearance, making it perfect for
rooftop installation


► Higher Module Conversion Efficiency:

Higher module output up to 400W with module efficiency up to 20.31%


► Low-light Performance:

Advanced glass and surface texturing allow for excellent performance in low-light environments


Advantages of Solar Energy:


1. Solar energy is kind of universal, decentralized and no -polluting energy.


2. Solar energy is the energy of the sun, which reaches earth in the form of short wave radiation visible light and near ultraviolet light.


3. Solar energy helps considerably in maintaining the ecological balance through the process of photosynthesis and green house effect.


4. Solar energy is bound to achieve great economic importance in future because of depletion trend of convention energy sources.


Project Reference:


315W 320W 325W ERA Mono Advanced Glass 60 Cell Solar Panel Solar System Components 0


Packaging and delivery:


Container Size Units/Pallet(PCS) Weight/Pallet(KG) Pallet Measurment(mm) Units/Container (PCS)
20GP 30 590 1700x1120x1120 360
40HQ 30 590 1700x1120x1135 938
37 686 1700x1120x1400


315W 320W 325W ERA Mono Advanced Glass 60 Cell Solar Panel Solar System Components 1


► Package: strong and long distance transportation package


► Place of loading: Basic Seaport, China


► Payment Terms: L/C,D/A,D/P,T/T


► Delivery Detail: Delivery time:7--25 days after receiving customer’s deposits


Our Certificates:


315W 320W 325W ERA Mono Advanced Glass 60 Cell Solar Panel Solar System Components 2

315W 320W 325W ERA Mono Advanced Glass 60 Cell Solar Panel Solar System Components 3
