TPT Backsheet ERA Mono 60 Cell Advanced Glass Mono Solar Panel

Payment Terms : L/C, T/T Supply Ability : 1000 Watt/Watts
Place of Origin: CHINA Brand Name: TIANFON
Certification: SGS,ISO 9001,ISO 14001,OHSAS 18000 Model Number: Solar Panels

Detail Information

Size: 1640x992x35mm Weight: 17.75 Kg
Backsheet (color): TPT In Black Company Certificate: ISO9001,ISO14001,ISO18001
Front Cover (material / Thickness): Low-iron Tempered Glass / 3.2mm Cell (quantity / Material / Dimensions): 60 / Monocrystalline Silicon / 156.75x156.75mm
Frame (material / Color): Aluminum Hollow-chamber Frame On Each Side Anodized Aluminum Alloy / Silver Cables & Plug Connectors (protection Degree): 2x900mm / 4mm 2 & MC4 Compatible
Payment Terms: L/C, T/T
High Light:

Advanced Glass Mono Solar Panel


TPT Backsheet Mono Solar Panel


ERA Mono 60 Cell Solar Panel

Product Description


ERA 290W-310W Mono 60-Cell Advanced Glass Solar Panel


We have paced the whole nation in the field of PV industry, not only on its product lines, but also upon its innovation.


We serves global customers with high-quality products and professional services. The modules can be installed on residential and commercial rooftops, ground-mounted power plants, as floating arrays, and much more.


Other than our competitive prices for pv modules and related solar energy products, we also offer the most comprehensive and accessible customer support for you.




Module type: ESPHSC 290 295 300 305 310
Maximum Power(Wp) 290W 295W 300W 305W 310W
Open circuit Voltage(Voc) 38.3V 38.5V 38.7V 38.95V 39.2V
Short circuit Current(Isc) 9.58A 9.7A 9.8A 9.87A 9.95A
Maximum Power Voltage(Vm) 32.6V 32.8V 33V 33.25V 33.5V
Maximum Power Current(Im) 8.9A 9A 9.1A 9.18A 9.26A
Module efficiency 17.80% 18.10% 18.40% 18.60% 18.90%
Maximum Series Fuse 15A
Watts positive tolerance 0~+3%
Number of Diode 3
Standard Test Conditions 1000W/M²,25°C,AM1.5
Maximum System Voltage 1000V/DC
Temperature-Coefficient Isc +0.08558%/°C
Temperature-Coefficient Voc -0.29506%/°C
Temperature-Coefficient Pmpp -0.38001%/°C
Normal Operating Cell Temperature -40°C...+85°C
Load Capacity for the cover of the module (glass) 5400Pa(IEC61215)(snow)
Load Capacity for the front & back of the module 2400Pa(IEC61215)(wind)
Product Certificate TUV(IEC 61215,IEC 61730),CE, ROHS,PID Resisitant,INMETRO
Company Certificate ISO9001,ISO14001,ISO18001


Key Features:


► 5 Busbar Solar Cell:

Higher module output up to 310W with Passivated Emmiter Rear Contact


► Higher Module Conversion Efficiency:

Higher module output up to 315W with Passivated Emmiter Rear Contact


► Low-light Performance:

Advanced glass and surface texturing allow for excellent performance in low-light environments


Advantages of Solar Energy:


1. Solar energy is kind of universal, decentralized and no -polluting energy.


2. Solar energy is the energy of the sun, which reaches earth in the form of short wave radiation visible light and near ultraviolet light.


3. Solar energy helps considerably in maintaining the ecological balance through the process of photosynthesis and green house effect.


4. Solar energy is bound to achieve great economic importance in future because of depletion trend of convention energy sources.


Project Reference:


TPT Backsheet ERA Mono 60 Cell Advanced Glass Mono Solar Panel 0


Packaging and delivery:


Container Size Units/Pallet(PCS) Weight/Pallet(KG) Pallet Measurment(mm) Units/Container (PCS)
20GP 30 560 1700x1130x1120 360
40HQ 30 560 1700x1130x1120 938
37 688 1700x1130x1385


TPT Backsheet ERA Mono 60 Cell Advanced Glass Mono Solar Panel 1


► Package: strong and long distance transportation package


► Place of loading: Basic Seaport, China


► Payment Terms: L/C,D/A,D/P,T/T


► Delivery Detail: Delivery time:7--25 days after receiving customer’s deposits


Our Certificates:


TPT Backsheet ERA Mono 60 Cell Advanced Glass Mono Solar Panel 2

TPT Backsheet ERA Mono 60 Cell Advanced Glass Mono Solar Panel 3
